QUIZ 1- TIME LIMIT-20 MIN

Electrical and Electronics Basics QUIZ 1

1 / 14

7 e1708260269479

2 / 14

Which of the following is correct for Digital Circuits?

3 / 14

A priority encoder has four inputs I0, I1, I2, and I3 where I3 has the highest priority and I0 has the least priority. If I2 = 1, what will be the output?

4 / 14

The maximum rectification efficiency of a half-wave rectifier is

5 / 14

Find the approximate collector current in the given transistor circuit (Take current gain = 100)

1

6 / 14

Determine the current in the circuit of figure and power consumed and power factor of the circuit.

3 4

7 / 14

Which of the following gives the correct number of multiplexers required to build a 32 x 1 multiplexer?

8 / 14

.Which of the following options represent the correct reduction of (X+Y)(X+Z) ?

9 / 14

In this Circuit the Value of V is

8 e1708260408178

10 / 14

For the circuit shown in fig., the switch 'S' is in position 1 for a long time and it is moved to position 2 at t = 0. Determine i1(0+)

4 e1708261678742

11 / 14

In an RL type low-pass filter, R = 550 2 and fc=400 hertz. Determine the value of L

12 / 14

For a bipolar junction transistor, the common base current gain is 0.98 and the base current is 120 uA. Its common-emitter current gain will be:

13 / 14

What must be the input given to “R” when SR flip – flop is converted to JK flip – flop?

14 / 14

Find the output voltage if Ein=6V and the Zener breakdown voltage of the Zener diode is 10V.

2

Your score is

The average score is 40%

0%
